Analog Devices Inc. LTC2324HUKG-14#TRPBF

Manufacturer No:
LTC2324HUKG-14#TRPBF
Manufacturer:
Analog Devices Inc.
Package:
Tape & Reel (TR)
Description:
IC ADC 14BIT SAR 52QFN
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The LTC2324HUKG-14#TRPBF is a quad, 14-bit, 2MSPS per channel simultaneous sampling successive approximation register (SAR) analog-to-digital converter (ADC) produced by Analog Devices Inc. This component is designed for high-speed and high-accuracy data acquisition applications. It features a compact 52-lead QFN package and supports both LVDS and SPI data interfaces.

Key Specifications

ParameterValue
Number of Bits14
Sampling Rate2 MSPS per channel
Number of A/D Converters4
Input TypeDifferential
Supply Voltage (Digital)3.13 V to 3.47 V, 5 V
Supply Voltage (Analog)3.13 V to 3.47 V, 5 V
Package52-QFN (7x8)
Operating Temperature-40°C to 125°C
Moisture Sensitivity Level (MSL)1 (Unlimited)
Data InterfaceLVDS, SPI

Key Features

  • Simultaneous sampling of four channels
  • High-speed operation at 2 MSPS per channel
  • Low power consumption
  • Compact 52-lead QFN package
  • Support for both LVDS and SPI data interfaces
  • External or internal reference options
  • High accuracy and linearity

Applications

The LTC2324HUKG-14#TRPBF is suitable for a variety of high-speed data acquisition applications, including industrial automation, medical devices, test and measurement equipment, and automotive systems. Its simultaneous sampling capability makes it particularly useful in applications where synchronized data acquisition is critical.

Q & A

  1. What is the resolution of the LTC2324HUKG-14#TRPBF ADC?
    The LTC2324HUKG-14#TRPBF has a resolution of 14 bits.
  2. What is the sampling rate of the LTC2324HUKG-14#TRPBF?
    The sampling rate is 2 MSPS per channel.
  3. How many A/D converters are included in the LTC2324HUKG-14#TRPBF?
    The component includes four A/D converters.
  4. What type of inputs does the LTC2324HUKG-14#TRPBF support?
    The component supports differential inputs.
  5. What are the supply voltage ranges for the LTC2324HUKG-14#TRPBF?
    The supply voltage ranges are 3.13 V to 3.47 V and 5 V for both digital and analog supplies.
  6. What is the package type of the LTC2324HUKG-14#TRPBF?
    The package type is 52-QFN (7x8).
  7. What is the operating temperature range of the LTC2324HUKG-14#TRPBF?
    The operating temperature range is -40°C to 125°C.
  8. What data interfaces are supported by the LTC2324HUKG-14#TRPBF?
    The component supports both LVDS and SPI data interfaces.
  9. Can the LTC2324HUKG-14#TRPBF use an external or internal reference?
    Yes, the component can use either an external or internal reference.
  10. What is the moisture sensitivity level (MSL) of the LTC2324HUKG-14#TRPBF?
    The MSL is 1 (Unlimited).

Product Attributes

Number of Bits:14
Sampling Rate (Per Second):2M
Number of Inputs:4
Input Type:Differential
Data Interface:LVDS - Parallel, SPI
Configuration:S/H-ADC
Ratio - S/H:ADC:1:1
Number of A/D Converters:4
Architecture:SAR
Reference Type:External, Internal
Voltage - Supply, Analog:3.13V ~ 3.47V, 5V
Voltage - Supply, Digital:3.13V ~ 3.47V, 5V
Features:Simultaneous Sampling
Operating Temperature:-40°C ~ 125°C
Package / Case:52-WFQFN Exposed Pad
Supplier Device Package:52-QFN (7x8)
Mounting Type:Surface Mount
