Overview
The LTC2320HUKG-16#PBF is a high-speed, low-power, 16-bit, 8-channel simultaneous sampling analog-to-digital converter (ADC) manufactured by Analog Devices Inc. This device is part of the LTC2320 family and is designed for applications requiring high-speed data acquisition with low power consumption. It features a successive approximation register (SAR) architecture and supports differential inputs with a wide input common mode range, making it suitable for various industrial and harsh environment applications.
Key Specifications
| Parameter | Description | Value |
|---|---|---|
| Resolution | Number of bits | 16 bits |
| Sampling Rate | Throughput rate per channel | 1.5 Msps |
| Number of Channels | Simultaneous sampling channels | 8 differential input channels |
| Input Type | Type of input signals | Differential |
| Supply Voltage | Analog and digital supply voltage range | 3.13V to 3.47V (analog and digital), 5V |
| Operating Temperature Range | Temperature range for operation | -40°C to 125°C |
| Package Type | Package and pin configuration | 52-QFN (7x8) with exposed pad |
| Data Interface | Supported data interfaces | LVDS, parallel, SPI |
| Reference Options | External and internal reference options | 2.048V or 4.096V internal reference |
| Power Dissipation | Power consumption per channel | 20mW per channel (typical) |
Key Features
- High-speed 16-bit ADC with simultaneous sampling capability for efficient data acquisition.
- Low power consumption for energy-efficient designs.
- Flexible interface options including LVDS, parallel, and SPI for easy system integration.
- Wide operating temperature range suitable for industrial and harsh environments.
- Robust packaging and pinout for reliable performance.
- Onboard low drift (20ppm/°C max) 2.048V or 4.096V temperature-compensated reference.
- High SNR (82dB typical) and low THD (90dB typical) at 500kHz input frequency.
- Nap and sleep modes to reduce power consumption to 26μW during inactive periods.
Applications
- Industrial data acquisition systems.
- Medical imaging equipment.
- Instrumentation and test equipment.
- Power monitoring and control systems.
Q & A
- What is the resolution of the LTC2320HUKG-16#PBF ADC?
The LTC2320HUKG-16#PBF has a 16-bit resolution.
- What is the sampling rate of the LTC2320HUKG-16#PBF?
The sampling rate is 1.5 Msps per channel.
- How many channels does the LTC2320HUKG-16#PBF support?
The device supports 8 differential input channels with simultaneous sampling capability.
- What are the supported data interfaces for the LTC2320HUKG-16#PBF?
The device supports LVDS, parallel, and SPI data interfaces.
- What is the operating temperature range of the LTC2320HUKG-16#PBF?
The operating temperature range is -40°C to 125°C.
- What is the power consumption per channel of the LTC2320HUKG-16#PBF?
The power consumption is typically 20mW per channel.
- Does the LTC2320HUKG-16#PBF have internal reference options?
Yes, it has onboard low drift (20ppm/°C max) 2.048V or 4.096V temperature-compensated reference options.
- What are the typical SNR and THD values for the LTC2320HUKG-16#PBF at 500kHz input frequency?
The typical SNR is 82dB and the typical THD is 90dB at 500kHz input frequency.
- Does the LTC2320HUKG-16#PBF have power-saving modes?
Yes, it has nap and sleep modes to reduce power consumption to 26μW during inactive periods.
- What are some common applications of the LTC2320HUKG-16#PBF?
Common applications include industrial data acquisition systems, medical imaging equipment, instrumentation and test equipment, and power monitoring and control systems.
