Analog Devices Inc. LTC2158CUP-12#PBF

Manufacturer No:
LTC2158CUP-12#PBF
Manufacturer:
Analog Devices Inc.
Package:
Tube
Description:
IC ADC 12BIT PIPELINED 64QFN
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The LTC2158CUP-12#PBF is a high-performance, 12-bit dual analog-to-digital converter (ADC) produced by Analog Devices Inc. This component is designed for demanding applications in industrial and medical fields, offering high-speed conversion and simultaneous sampling capabilities. It features a pipelined architecture and supports multiple data interfaces, making it versatile for various high-speed data acquisition needs.

Key Specifications

Parameter Value
Manufacturer Analog Devices Inc.
Part Number LTC2158CUP-12#PBF
Description IC ADC 12BIT DUAL 310MSPS
Package / Case 64-QFN (9x9)
Number of Bits 12
Number of A/D Converters 2
Sampling Rate (Per Second) 310 MS/s
Analog Supply Voltage 1.74 V ~ 1.9 V
Digital Supply Voltage 1.74 V ~ 1.9 V
Input Type Differential
Reference Type External, Internal
Operating Temperature 0°C ~ 70°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Lead Free Status / RoHS Status Lead free / RoHS Compliant
Data Interface LVDS - Parallel
Architecture Pipelined
Features Simultaneous Sampling

Key Features

  • High-Speed Conversion: The LTC2158CUP-12#PBF offers a sampling rate of 310 MS/s, making it suitable for high-speed data acquisition applications.
  • Dual Channel: This ADC features two simultaneous sampling channels, enhancing its capability in multi-channel applications.
  • Pipelined Architecture: The pipelined architecture ensures high-speed conversion with minimal latency.
  • Multiple Data Interfaces: Supports LVDS and parallel data interfaces, providing flexibility in system design.
  • Low Power Consumption: With a power dissipation of 688 mW, it is energy-efficient for various applications.
  • High Accuracy: Features low differential nonlinearity (DNL) and integral nonlinearity (INL) of 0.1 LSB and 0.6 LSB, respectively, ensuring high accuracy in conversions.
  • RoHS Compliant: Lead-free and RoHS compliant, making it environmentally friendly and compliant with regulatory standards.

Applications

  • Industrial Automation: Suitable for high-speed data acquisition in industrial control systems and automation.
  • Medical Imaging: Used in medical imaging equipment due to its high-speed and high-accuracy conversion capabilities.
  • Test and Measurement: Ideal for test and measurement equipment requiring simultaneous sampling and high-speed data conversion.
  • Aerospace and Defense: Can be used in various aerospace and defense applications where high-speed and accurate data conversion is critical.

Q & A

  1. What is the sampling rate of the LTC2158CUP-12#PBF?

    The sampling rate of the LTC2158CUP-12#PBF is 310 MS/s.

  2. How many channels does the LTC2158CUP-12#PBF have?

    The LTC2158CUP-12#PBF has two simultaneous sampling channels.

  3. What is the architecture of the LTC2158CUP-12#PBF?

    The architecture of the LTC2158CUP-12#PBF is pipelined.

  4. What are the supported data interfaces for the LTC2158CUP-12#PBF?

    The LTC2158CUP-12#PBF supports LVDS and parallel data interfaces.

  5. What is the power dissipation of the LTC2158CUP-12#PBF?

    The power dissipation of the LTC2158CUP-12#PBF is 688 mW.

  6. Is the LTC2158CUP-12#PBF RoHS compliant?

    Yes, the LTC2158CUP-12#PBF is lead-free and RoHS compliant.

  7. What is the operating temperature range of the LTC2158CUP-12#PBF?

    The operating temperature range of the LTC2158CUP-12#PBF is 0°C ~ 70°C.

  8. What is the input type of the LTC2158CUP-12#PBF?

    The input type of the LTC2158CUP-12#PBF is differential.

  9. What are the typical applications of the LTC2158CUP-12#PBF?

    The LTC2158CUP-12#PBF is typically used in industrial automation, medical imaging, test and measurement, and aerospace and defense applications.

  10. What is the package type of the LTC2158CUP-12#PBF?

    The package type of the LTC2158CUP-12#PBF is 64-QFN (9x9).

Product Attributes

Number of Bits:12
Sampling Rate (Per Second):310M
Number of Inputs:2
Input Type:Differential
Data Interface:LVDS - Parallel
Configuration:S/H-ADC
Ratio - S/H:ADC:1:1
Number of A/D Converters:2
Architecture:Pipelined
Reference Type:External, Internal
Voltage - Supply, Analog:1.74V ~ 1.9V
Voltage - Supply, Digital:1.74V ~ 1.9V
Features:Simultaneous Sampling
Operating Temperature:0°C ~ 70°C
Package / Case:64-WFQFN Exposed Pad
Supplier Device Package:64-QFN (9x9)
Mounting Type:Surface Mount
0 Remaining View Similar

In Stock

-
440

Please send RFQ , we will respond immediately.

Same Series
LTC2158CUP-12#TRPBF
LTC2158CUP-12#TRPBF
IC ADC 12BIT PIPELINED 64QFN
LTC2158IUP-12#TRPBF
LTC2158IUP-12#TRPBF
IC ADC 12BIT PIPELINED 64QFN

Similar Products

Part Number LTC2158CUP-12#PBF LTC2155CUP-12#PBF LTC2156CUP-12#PBF LTC2157CUP-12#PBF
Manufacturer Analog Devices Inc. Analog Devices Inc. Analog Devices Inc. Analog Devices Inc.
Product Status Active Active Active Active
Number of Bits 12 12 12 12
Sampling Rate (Per Second) 310M 170M 210M 250M
Number of Inputs 2 2 2 2
Input Type Differential Differential Differential Differential
Data Interface LVDS - Parallel LVDS - Parallel LVDS - Parallel LVDS - Parallel
Configuration S/H-ADC S/H-ADC S/H-ADC S/H-ADC
Ratio - S/H:ADC 1:1 1:1 1:1 1:1
Number of A/D Converters 2 2 2 2
Architecture Pipelined Pipelined Pipelined Pipelined
Reference Type External, Internal External, Internal External, Internal External, Internal
Voltage - Supply, Analog 1.74V ~ 1.9V 1.7V ~ 1.9V 1.7V ~ 1.9V 1.7V ~ 1.9V
Voltage - Supply, Digital 1.74V ~ 1.9V 1.7V ~ 1.9V 1.7V ~ 1.9V 1.7V ~ 1.9V
Features Simultaneous Sampling Simultaneous Sampling Simultaneous Sampling Simultaneous Sampling
Operating Temperature 0°C ~ 70°C 0°C ~ 70°C 0°C ~ 70°C 0°C ~ 70°C
Package / Case 64-WFQFN Exposed Pad 64-WFQFN Exposed Pad 64-WFQFN Exposed Pad 64-WFQFN Exposed Pad
Supplier Device Package 64-QFN (9x9) 64-QFN (9x9) 64-QFN (9x9) 64-QFN (9x9)
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount
