Product Introduction

Overview

The LTC2156IUP-12#PBF is a high-performance, dual 12-bit analog-to-digital converter (ADC) manufactured by Analog Devices Inc. This component is designed for applications requiring the digitization of high-frequency, wide dynamic range signals. It features a pipelined architecture and simultaneous sampling capabilities, making it ideal for demanding communications and data acquisition systems.

Key Specifications

Part Number LTC2156IUP-12#PBF
Manufacturer Analog Devices Inc.
Description IC ADC DUAL 12BIT 210MSPS 64-QFN
Lead Free Status / RoHS Status Lead free / RoHS Compliant
Voltage - Supply, Digital 1.7 V ~ 1.9 V
Voltage - Supply, Analog 1.7 V ~ 1.9 V
Package / Case 64-WFQFN Exposed Pad
Operating Temperature -40°C ~ 85°C
Number of Inputs 2
Number of Bits 12
Number of A/D Converters 2
Sampling Rate (Per Second) 210M
Reference Type External, Internal
Input Type Differential
Data Interface LVDS - Parallel
Architecture Pipelined

Key Features

  • Simultaneous Sampling: Both ADCs sample the input signals simultaneously, ensuring synchronized data acquisition.
  • High Sampling Rate: The LTC2156IUP-12#PBF operates at a sampling rate of 210 MSPS, making it suitable for high-speed applications.
  • Low Power Consumption: The device operates with a total power consumption of 592mW, which is efficient for many modern systems.
  • High SNR and SFDR: It offers a signal-to-noise ratio (SNR) of 68.5 dB and a spurious free dynamic range (SFDR) of 90 dB, ensuring high signal integrity.
  • Single 1.8V Supply: The ADC operates on a single 1.8V supply, simplifying power management in the system.
  • DDR LVDS Outputs: The device features double data rate (DDR) LVDS outputs, which facilitate high-speed data transfer.
  • 1.25GHz Full-Power Bandwidth: The input bandwidth allows for high undersampling ratios with minimal attenuation.

Applications

  • Communications Systems: Ideal for digitizing high-frequency signals in wireless communication systems, such as 5G and other high-speed networks.
  • Data Acquisition Systems: Suitable for high-speed data acquisition in various industrial and scientific applications.
  • Testing and Measurement Instruments: Used in oscilloscopes, spectrum analyzers, and other measurement equipment requiring high-speed and high-accuracy ADCs.
  • Radar and Aerospace: Applicable in radar systems and aerospace applications where high-speed and high-resolution ADCs are necessary.

Q & A

  1. What is the sampling rate of the LTC2156IUP-12#PBF?

    The sampling rate of the LTC2156IUP-12#PBF is 210 MSPS.

  2. How many bits does each ADC in the LTC2156IUP-12#PBF have?

    Each ADC in the LTC2156IUP-12#PBF is a 12-bit converter.

  3. What is the operating temperature range of the LTC2156IUP-12#PBF?

    The operating temperature range is -40°C to 85°C.

  4. Does the LTC2156IUP-12#PBF support simultaneous sampling?
  5. What type of data interface does the LTC2156IUP-12#PBF use?

    The device uses LVDS (Low Voltage Differential Signaling) parallel data interface.

  6. What is the power consumption of the LTC2156IUP-12#PBF?

    The total power consumption is approximately 592mW.

  7. Is the LTC2156IUP-12#PBF RoHS compliant?
  8. What is the input bandwidth of the LTC2156IUP-12#PBF?

    The input bandwidth is 1.25GHz.

  9. What are the typical applications of the LTC2156IUP-12#PBF?

    Typical applications include communications systems, data acquisition systems, testing and measurement instruments, and radar/aerospace systems.

  10. What is the architecture of the ADCs in the LTC2156IUP-12#PBF?

    The ADCs in the LTC2156IUP-12#PBF use a pipelined architecture.

Product Attributes

Number of Bits:12
Sampling Rate (Per Second):210M
Number of Inputs:2
Input Type:Differential
Data Interface:LVDS - Parallel
Configuration:S/H-ADC
Ratio - S/H:ADC:1:1
Number of A/D Converters:2
Architecture:Pipelined
Reference Type:External, Internal
Voltage - Supply, Analog:1.7V ~ 1.9V
Voltage - Supply, Digital:1.7V ~ 1.9V
Features:Simultaneous Sampling
Operating Temperature:-40°C ~ 85°C
Package / Case:64-WFQFN Exposed Pad
Supplier Device Package:64-QFN (9x9)
Mounting Type:Surface Mount
