Overview
The LT1997HMS-2#PBF is a specialized integrated circuit produced by Analog Devices Inc. It is an attenuating (funnel) difference amplifier designed to translate large differential signals into a low voltage range, making it compatible with low-voltage systems. This component is particularly useful in applications where signal attenuation and translation are necessary.
Key Specifications
| Parameter | Value |
|---|---|
| Package Type | 16-MSOP |
| Number of Circuits | 1 |
| Operating Temperature Range | -40°C to 125°C |
| Supply Voltage | ±2.5V to ±18V |
| Input Offset Voltage | Typically 100μV |
| Gain Bandwidth Product | 10 MHz |
| Common Mode Rejection Ratio (CMRR) | Typically 80 dB |
Key Features
- Attenuating (funnel) difference amplifier
- Translates large differential signals to low voltage range
- High common mode rejection ratio (CMRR)
- Wide operating temperature range (-40°C to 125°C)
- Low input offset voltage
- Compact 16-MSOP package
Applications
- Industrial control systems
- Medical devices
- Aerospace and defense systems
- Automotive systems
- High-precision measurement and instrumentation
Q & A
- What is the primary function of the LT1997HMS-2#PBF? The primary function is to translate large differential signals into a low voltage range.
- What is the operating temperature range of the LT1997HMS-2#PBF? The operating temperature range is -40°C to 125°C.
- What is the typical input offset voltage of the LT1997HMS-2#PBF? The typical input offset voltage is 100μV.
- What is the common mode rejection ratio (CMRR) of the LT1997HMS-2#PBF? The CMRR is typically 80 dB.
- In what package is the LT1997HMS-2#PBF available? It is available in a 16-MSOP package.
- What are some common applications of the LT1997HMS-2#PBF? Common applications include industrial control systems, medical devices, aerospace and defense systems, and high-precision measurement and instrumentation.
- What is the gain bandwidth product of the LT1997HMS-2#PBF? The gain bandwidth product is 10 MHz.
- What is the supply voltage range for the LT1997HMS-2#PBF? The supply voltage range is ±2.5V to ±18V.
- Is the LT1997HMS-2#PBF suitable for high-precision applications? Yes, it is suitable due to its low input offset voltage and high CMRR.
- Where can I find detailed specifications and datasheets for the LT1997HMS-2#PBF? Detailed specifications and datasheets can be found on the Analog Devices website and through distributors like Digi-Key and Richardson RFPD.
