Overview
The ADUC824BSZ-DEN, produced by Analog Devices Inc., is a highly integrated 24-bit data acquisition system-on-a-chip. This MicroConverter device combines a high-performance analog-to-digital converter (ADC) with a microcontroller, making it a versatile solution for various data acquisition and control applications. The ADUC824 features a precision 24-bit sigma-delta ADC, an 8-bit microcontroller with 8KB of flash memory, and a range of peripheral functions, including digital I/O, timers, and serial communication interfaces.
Key Specifications
| Parameter | Specification |
|---|---|
| ADC Resolution | 24-bit sigma-delta |
| Microcontroller Type | 8-bit |
| Flash Memory | 8KB |
| Digital I/O | Available |
| Timers | Available |
| Serial Communication Interfaces | Available (e.g., SPI, UART) |
| Operating Temperature Range | -40°C to +85°C |
| Package Type | 28-lead SSOP |
Key Features
- Precision 24-bit Sigma-Delta ADC: High-resolution analog-to-digital conversion for accurate data acquisition.
- 8-bit Microcontroller: Integrated microcontroller with 8KB of flash memory for program storage and execution.
- Digital I/O and Timers: Provides flexibility for interfacing with external devices and managing timing-critical tasks.
- Serial Communication Interfaces: Supports SPI and UART for communication with other devices.
- Low Power Consumption: Optimized for low power operation, making it suitable for battery-powered applications.
Applications
- Industrial Automation: Used in control systems, monitoring, and data logging applications.
- Medical Devices: Suitable for medical equipment requiring high precision and reliability.
- Environmental Monitoring: Ideal for monitoring temperature, pressure, and other environmental parameters.
- Aerospace and Defense: Used in various military and aerospace applications requiring high reliability and precision.
Q & A
- What is the resolution of the ADC in the ADUC824BSZ-DEN?
The ADUC824BSZ-DEN features a 24-bit sigma-delta ADC.
- What type of microcontroller is integrated into the ADUC824BSZ-DEN?
The device includes an 8-bit microcontroller.
- How much flash memory does the ADUC824BSZ-DEN have?
The device has 8KB of flash memory.
- What are the available communication interfaces on the ADUC824BSZ-DEN?
The device supports SPI and UART serial communication interfaces.
- What is the operating temperature range of the ADUC824BSZ-DEN?
The operating temperature range is -40°C to +85°C.
- In what package type is the ADUC824BSZ-DEN available?
The device is available in a 28-lead SSOP package.
- What are some typical applications of the ADUC824BSZ-DEN?
Typical applications include industrial automation, medical devices, environmental monitoring, and aerospace and defense.
- Is the ADUC824BSZ-DEN suitable for low power applications?
Yes, the device is optimized for low power consumption, making it suitable for battery-powered applications.
- Where can I find detailed specifications and datasheets for the ADUC824BSZ-DEN?
Detailed specifications and datasheets can be found on the official Analog Devices website and through distributors like Digi-Key and Mouser Electronics.
- What kind of digital I/O and timers are available on the ADUC824BSZ-DEN?
The device includes digital I/O and timers for managing external interfaces and timing-critical tasks.
