Overview
The AD9731BRS-REEL is a high-performance, 10-bit digital-to-analog converter (DAC) produced by Analog Devices Inc. This component is designed to operate at a sampling rate of up to 170 MSPS, making it suitable for a variety of high-speed applications. The AD9731BRS-REEL is packaged in a 28-lead Shrink Small Outline Package (SSOP) and is available in a reel format, which is convenient for automated assembly processes.
Key Specifications
| Parameter | Value |
|---|---|
| Resolution | 10 bits |
| Sampling Rate | Up to 170 MSPS |
| Package Type | 28-Lead Shrink Small Outline Package (SSOP) |
| Operating Temperature Range | –40°C to +85°C |
| Power Supply | Dual supply: +3.3V and +1.8V |
| DAC Architecture | Current Steering |
Key Features
- High-speed operation up to 170 MSPS
- 10-bit resolution for precise analog output
- Dual power supply: +3.3V and +1.8V for flexible power management
- Current steering architecture for high accuracy and linearity
- Compact 28-lead SSOP package for space-efficient designs
Applications
The AD9731BRS-REEL is ideal for various high-speed applications, including:
- Wireless communication systems
- Medical imaging and diagnostics
- Radar and surveillance systems
- Test and measurement equipment
- High-speed data acquisition systems
Q & A
- What is the resolution of the AD9731BRS-REEL DAC? The AD9731BRS-REEL has a 10-bit resolution.
- What is the maximum sampling rate of the AD9731BRS-REEL? The maximum sampling rate is up to 170 MSPS.
- What is the package type of the AD9731BRS-REEL? It is packaged in a 28-lead Shrink Small Outline Package (SSOP).
- What is the operating temperature range of the AD9731BRS-REEL? The operating temperature range is –40°C to +85°C.
- What power supplies are required for the AD9731BRS-REEL? It requires dual power supplies: +3.3V and +1.8V.
- What is the DAC architecture of the AD9731BRS-REEL? The DAC architecture is current steering.
- What are some typical applications of the AD9731BRS-REEL? Typical applications include wireless communication systems, medical imaging, radar and surveillance systems, test and measurement equipment, and high-speed data acquisition systems.
- Is the AD9731BRS-REEL available in reel format? Yes, it is available in reel format for automated assembly.
- Where can I find detailed specifications for the AD9731BRS-REEL? Detailed specifications can be found in the data sheet available on Analog Devices' official website and other authorized distributors.
- What is the significance of the 'REEL' suffix in the part number? The 'REEL' suffix indicates that the component is supplied in a reel format, suitable for automated assembly processes.
