Overview
The AD9230BCPZ11-200 is a high-performance, 11-bit analog-to-digital converter (ADC) produced by Analog Devices Inc. This device is designed to operate at a sampling rate of 200 MSPS (mega-samples per second), making it suitable for a variety of high-speed applications. The ADC features a pipelined architecture and operates on a 1.8V supply voltage, ensuring low power consumption while maintaining high accuracy and speed.
Key Specifications
| Parameter | Value |
|---|---|
| Resolution | 11 bits |
| Sampling Rate | 200 MSPS |
| Supply Voltage | 1.8 V |
| Operating Temperature | -40°C to +85°C |
| Package Type | 56-Lead Lead Frame Chip Scale Package (LFCSP-VQ) |
| Number of Inputs | 1 |
| Architecture | Pipelined |
Key Features
- High-speed sampling rate of 200 MSPS
- Low power consumption with a 1.8V supply voltage
- Pipelined architecture for high throughput
- Compact 56-Lead LFCSP-VQ package
- Operating temperature range from -40°C to +85°C
Applications
The AD9230BCPZ11-200 is ideal for various high-speed data acquisition applications, including:
- Medical Imaging
- Radar and Aerospace Systems
- High-Speed Data Acquisition Systems
- Test and Measurement Equipment
- Wireless Communication Systems
Q & A
- What is the resolution of the AD9230BCPZ11-200?
The AD9230BCPZ11-200 has a resolution of 11 bits. - What is the maximum sampling rate of the AD9230BCPZ11-200?
The maximum sampling rate is 200 MSPS. - What is the supply voltage for the AD9230BCPZ11-200?
The supply voltage is 1.8 V. - What is the operating temperature range for the AD9230BCPZ11-200?
The operating temperature range is from -40°C to +85°C. - What type of package does the AD9230BCPZ11-200 come in?
The device comes in a 56-Lead Lead Frame Chip Scale Package (LFCSP-VQ). - How many inputs does the AD9230BCPZ11-200 have?
The device has one input. - What architecture does the AD9230BCPZ11-200 use?
The device uses a pipelined architecture. - What are some common applications for the AD9230BCPZ11-200?
Common applications include medical imaging, radar and aerospace systems, high-speed data acquisition systems, test and measurement equipment, and wireless communication systems. - Is the AD9230BCPZ11-200 currently in production?
Yes, the AD9230BCPZ11-200 is in production status. - What is the typical factory lead time for the AD9230BCPZ11-200?
The typical factory lead time is 10 weeks.
