Overview
The AD7572SQ05/883B is a 12-bit successive approximation (SAR) analog-to-digital converter (ADC) produced by Analog Devices Inc. This component is designed for high-performance applications requiring precise analog-to-digital conversion. It features a parallel interface for word access, making it suitable for a variety of industrial and military applications.
Key Specifications
| Parameter | Value |
|---|---|
| Resolution | 12 bits |
| Conversion Type | Successive Approximation (SAR) |
| Interface | Parallel, Word Access |
| Package | 24-CDIP (Ceramic Dual In-Line Package) |
| RoHS Status | Not Compliant |
| Operating Temperature | Military Grade (typically -55°C to 125°C) |
Key Features
- High-resolution 12-bit SAR ADC for precise analog-to-digital conversion.
- Parallel interface for word access, facilitating easy integration into various systems.
- Robust and reliable design suitable for industrial and military applications.
- Compact 24-CDIP package, optimizing space in dense system designs.
Applications
The AD7572SQ05/883B is versatile and can be used in a range of applications, including:
- Industrial control systems requiring high accuracy and reliability.
- Military and aerospace systems where robustness and precision are critical.
- Medical devices that demand accurate analog-to-digital conversion.
- Data acquisition systems in various industries.
Q & A
- What is the resolution of the AD7572SQ05/883B ADC?
The AD7572SQ05/883B has a resolution of 12 bits. - What type of conversion does the AD7572SQ05/883B use?
The AD7572SQ05/883B uses successive approximation (SAR) conversion. - What is the interface type of the AD7572SQ05/883B?
The AD7572SQ05/883B features a parallel interface with word access. - What is the package type of the AD7572SQ05/883B?
The AD7572SQ05/883B comes in a 24-CDIP (Ceramic Dual In-Line Package). - Is the AD7572SQ05/883B RoHS compliant?
No, the AD7572SQ05/883B is not RoHS compliant. - What are the typical operating temperatures for the AD7572SQ05/883B?
The AD7572SQ05/883B operates within the military temperature range, typically -55°C to 125°C. - Where can the AD7572SQ05/883B be used?
The AD7572SQ05/883B can be used in industrial control systems, military and aerospace systems, medical devices, and data acquisition systems. - Why is the AD7572SQ05/883B preferred in military applications?
The AD7572SQ05/883B is preferred in military applications due to its robust design, high accuracy, and ability to operate over a wide temperature range. - How does the parallel interface of the AD7572SQ05/883B benefit system design?
The parallel interface of the AD7572SQ05/883B allows for easy integration and faster data transfer rates, which is beneficial in systems requiring high-speed data acquisition. - What are some key features of the AD7572SQ05/883B?
Key features include high-resolution 12-bit SAR ADC, parallel interface, robust and reliable design, and a compact 24-CDIP package.
