Overview
The AD1380JD is a 16-bit analog-to-digital converter (ADC) produced by Analog Devices Inc. This integrated circuit is designed for high-precision data conversion and is widely used in various applications requiring accurate analog-to-digital signal processing.
Key Specifications
| Parameter | Value |
|---|---|
| Resolution | 16 bits |
| Conversion Type | SAR (Successive Approximation Register) |
| Number of Inputs | 16 |
| Package Type | 32-BDIP (Bent DIP) |
| Operating Temperature Range | -40°C to +85°C (typical) |
Key Features
- High resolution of 16 bits for precise data conversion.
- SAR architecture for efficient and accurate conversions.
- Supports 16 input channels, making it versatile for multiple signal processing tasks.
- Available in a 32-BDIP package, suitable for a variety of board designs.
- Operates over a wide temperature range, enhancing reliability in diverse environments.
Applications
The AD1380JD is suitable for a range of applications including industrial control systems, medical devices, data acquisition systems, and any scenario where high-precision analog-to-digital conversion is required.
Q & A
- What is the resolution of the AD1380JD ADC?
The AD1380JD has a resolution of 16 bits. - What type of conversion does the AD1380JD use?
The AD1380JD uses SAR (Successive Approximation Register) conversion. - How many input channels does the AD1380JD support?
The AD1380JD supports 16 input channels. - What is the package type of the AD1380JD?
The AD1380JD is available in a 32-BDIP package. - What is the operating temperature range of the AD1380JD?
The operating temperature range is typically -40°C to +85°C. - Where can I purchase the AD1380JD?
The AD1380JD can be purchased from distributors such as Mouser Electronics, Digi-Key, and AERI. - What are some common applications for the AD1380JD?
Common applications include industrial control systems, medical devices, and data acquisition systems. - Is the AD1380JD suitable for high-precision applications?
Yes, the AD1380JD is designed for high-precision analog-to-digital conversion. - Can the AD1380JD operate in harsh environments?
Yes, it can operate over a wide temperature range, making it suitable for harsh environments. - What is the typical price range for the AD1380JD?
The price can vary but is typically around USD 634.96 or similar, depending on the distributor and quantity.
