Overview
The 5962-9684601QLA is an analog-to-digital converter (ADC) produced by Analog Devices Inc. This component is part of the company's extensive range of data acquisition solutions, designed to convert analog signals into digital data with high precision and reliability.
This ADC is particularly suited for applications requiring robust performance across a wide range of temperatures and operating conditions, making it a versatile choice for various industrial, aerospace, and defense applications.
Key Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Part Number | 5962-9684601QLA |
| Package Type | 40-CDIP (0.600", 15.24mm) |
| Packing Method | Tube |
| Interface Type | Parallel |
| Operating Temperature Range | -55 °C ~ 125 °C |
| Operating Supply Voltage | ±10.8 V ~ 13.2 V |
| Resolution | 12 bits |
| Number of A/D Converters | 1 |
| Reference Type | External, Internal |
Key Features
- High Resolution: The 5962-9684601QLA offers a 12-bit resolution, ensuring precise conversion of analog signals to digital data.
- Wide Operating Temperature Range: This ADC operates reliably across a temperature range of -55 °C to 125 °C, making it suitable for harsh environments.
- Parallel Interface: The component features a parallel interface, facilitating high-speed data transfer and integration with various systems.
- Dual Supply Voltage: It supports dual supply voltages (±10.8 V ~ 13.2 V), providing flexibility in system design.
- External and Internal Reference: The ADC can use both external and internal references, offering flexibility in calibration and accuracy.
Applications
- Industrial Automation: Suitable for industrial control systems, process monitoring, and automation where precise and reliable data conversion is critical.
- Aerospace and Defense: Its robust performance across a wide temperature range makes it ideal for aerospace and defense applications where reliability is paramount.
- Medical Devices: Can be used in medical equipment requiring high precision and reliability in data acquisition.
- Test and Measurement: Ideal for test and measurement instruments that require accurate and reliable analog-to-digital conversion.
