Overview
The 5962-8865804XA is a high-performance analog-to-digital converter (ADC) produced by Analog Devices Inc. This component is designed for applications requiring precise and reliable analog-to-digital conversion. It is part of Analog Devices' extensive range of ADCs, known for their high accuracy and robust performance in various environmental conditions.
Key Specifications
| Specification | Value |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Part Number | 5962-8865804XA |
| Type | Single ADC, Successive Approximation (SAR) |
| Number of Bits | 12 |
| Data Interface | Parallel/Serial |
| Package Type | 28-CDIP (0.600", 15.24mm) |
| Packing Method | Tube |
| Operating Temperature Range | -55 °C to 125 °C |
| Operating Supply Voltage | ±10.8 V ~ 13.2 V |
Key Features
- High Resolution: 12-bit resolution for precise analog-to-digital conversion.
- Dual Interface: Supports both parallel and serial data interfaces for flexibility in system design.
- Wide Operating Temperature Range: Operates reliably from -55 °C to 125 °C, making it suitable for harsh environments.
- Robust Packaging: 28-CDIP package ensures durability and ease of integration into various systems.
Applications
The 5962-8865804XA is suitable for a variety of applications, including:
- Aerospace and Defense: Given its wide operating temperature range and high reliability, it is often used in military and aerospace systems.
- Industrial Automation: Used in industrial control systems where precise and reliable data conversion is critical.
- Medical Devices: Applied in medical equipment that requires accurate and stable analog-to-digital conversion.
- Test and Measurement: Utilized in test and measurement instruments for precise data acquisition.
Q & A
- What is the resolution of the 5962-8865804XA ADC?
The 5962-8865804XA has a 12-bit resolution. - What are the supported data interfaces for this ADC?
The ADC supports both parallel and serial data interfaces. - What is the operating temperature range of the 5962-8865804XA?
The operating temperature range is from -55 °C to 125 °C. - What is the package type of the 5962-8865804XA?
The package type is 28-CDIP (0.600", 15.24mm). - What is the typical application of the 5962-8865804XA in the aerospace industry?
In the aerospace industry, it is used for its high reliability and wide operating temperature range, making it suitable for various military and aerospace systems. - Can the 5962-8865804XA be used in medical devices?
Yes, it is used in medical devices due to its high accuracy and stability in analog-to-digital conversion. - What is the operating supply voltage range for the 5962-8865804XA?
The operating supply voltage range is ±10.8 V ~ 13.2 V. - Is the 5962-8865804XA suitable for industrial automation?
Yes, it is widely used in industrial control systems where precise data conversion is necessary. - Where can I find detailed specifications for the 5962-8865804XA?
Detailed specifications can be found on the official Analog Devices website, as well as on distributor websites such as Digi-Key, Mouser, and Rochester Electronics. - What is the packing method for the 5962-8865804XA?
The packing method is tube packaging.
