Overview
The TM4C123GH6ZRBI is a high-performance microcontroller from Texas Instruments, designed for a wide range of embedded applications. This model belongs to the Tiva™ C Series ARM® Cortex®-M4 microcontrollers, offering a balance of performance, power efficiency, and integration. It is particularly suited for applications requiring real-time control, connectivity, and advanced peripherals. The TM4C123GH6ZRBI targets industries such as industrial automation, consumer electronics, automotive, and IoT, making it a versatile choice for developers seeking a robust and scalable solution.
Key Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Core | ARM Cortex-M4 | With FPU | |
| Clock Speed | 80 | MHz | |
| Flash Memory | 256 | KB | |
| SRAM | 32 | KB | |
| Operating Voltage | 1.2 to 3.6 | V | |
| GPIO Pins | 43 | ||
| Communication Interfaces | UART, SPI, I2C, CAN | ||
| Package | LQFP | 64-pin | |
| Operating Temperature | -40 to 85 | °C | |
| Manufacturer | Texas Instruments |
Key Features
- ARM Cortex-M4 core with Floating Point Unit (FPU) for efficient signal processing.
- Integrated 256 KB Flash and 32 KB SRAM for ample program and data storage.
- Multiple communication interfaces including UART, SPI, I2C, and CAN for versatile connectivity.
- Low power consumption with a wide operating voltage range of 1.2 to 3.6 V.
- Robust GPIO support with 43 configurable pins.
- Comprehensive development tools and software libraries for accelerated design cycles.
Applications
The TM4C123GH6ZRBI is widely used in various industries due to its advanced features and flexibility. In industrial automation, it is employed for real-time control and monitoring systems. In consumer electronics, it powers smart devices and IoT applications. Automotive systems benefit from its robust communication interfaces and low power consumption. Additionally, it is a popular choice for educational and prototyping projects, thanks to its ease of use and extensive support from Texas Instruments.
Q & A
1. What is the core architecture of the TM4C123GH6ZRBI?
The TM4C123GH6ZRBI is based on the ARM Cortex-M4 core with a Floating Point Unit (FPU).
2. What is the maximum clock speed of this microcontroller?
The maximum clock speed is 80 MHz.
3. How much Flash memory does the TM4C123GH6ZRBI have?
It has 256 KB of Flash memory.
4. What is the operating voltage range?
The operating voltage ranges from 1.2 to 3.6 V.
5. How many GPIO pins are available?
There are 43 GPIO pins.
6. What communication interfaces are supported?
It supports UART, SPI, I2C, and CAN interfaces.
7. What is the package type of the TM4C123GH6ZRBI?
It comes in a 64-pin LQFP package.
8. What is the operating temperature range?
The operating temperature ranges from -40 to 85 °C.
9. Is the TM4C123GH6ZRBI suitable for IoT applications?
Yes, its low power consumption and versatile connectivity make it ideal for IoT applications.
10. What development tools are available for this microcontroller?
Texas Instruments provides comprehensive development tools, including the TivaWare™ software suite and Code Composer Studio™ IDE.
